8 100M Rj45 Ports 1 100M Uplink Port 9 Port Ethernet Switch

8 100M Rj45 Ports 1 100M Uplink Port 9 Port Ethernet Switch
8 100M Rj45 Ports 1 100M Uplink Port 9 Port Ethernet Switch 8 100M Rj45 Ports 1 100M Uplink Port 9 Port Ethernet Switch 8 100M Rj45 Ports 1 100M Uplink Port 9 Port Ethernet Switch 8 100M Rj45 Ports 1 100M Uplink Port 9 Port Ethernet Switch

Large Image :  8 100M Rj45 Ports 1 100M Uplink Port 9 Port Ethernet Switch

Product Details:
Place of Origin: China, Guang dong
Brand Name: Hioso
Certification: CE, RoHS, CCC
Model Number: Foway2209PF
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 38X24X18 CM
Delivery Time: 2-12 work days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000 pcs/month

8 100M Rj45 Ports 1 100M Uplink Port 9 Port Ethernet Switch

Description
Name: POE Switch Standard: IEEE802.3af/at
Distance: CAT5: 100M Cache Space: 1 Mbit
Working: -10~60℃ Storage: -40~80℃
High Light:

100M Rj45 Ports 9 port ethernet switch

,

100M Uplink Port 9 port ethernet switch

,

100M Rj45 Ports gigabit poe

9 Ports Poe Switch 8 100M Rj45 Poe Ports + 1 100M Uplink Port



Overview



HiOSO Foway2209PF series 8 ports 100M Security Industrial PoE Ethernet Switches, supply 8 10/100M RJ45 PoE ports and 1 100M FX fiber uplink port; support auto discovery IEEE802.3af/at standard powered devices,auto stop powering the non standard poe devices;support to supply power to IP cameras,VoIP phones,wireless access points and other network devices;support to choose web or SNMP management; support to transmit HD video flow; apply to Security system, electronic power system and traffic system requirements.



Character

  • Support 8 10/100M RJ45 PoE ports and 1 100M FX fiber uplink port
  • Each PoE port supports auto detect the powered device
  • Support IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards
  • Support each port full rate, full-duplex non-blocking forwarding
  • Support WEB management and SNMP (optional)
  • Support 2K MAC learning, 1Mbit cache space, 2G back plane bandwidth
  • Each RJ45 port adopts anti-high voltage circuit, strengthen the lightning protection and anti-interference ability
  • Supply redundant dual power input ports, enhance reliability
  • Wall mounting design,external power,better for heat dissipating and installation

Technical Specification

Parameter Specification
Standard IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet,IEEE802.3x Flow control,IEEE802.1q VLAN,IEEE802.1p QoS, IEEE802.1d Spanning Tree,IEEE802.3af,IEEE802.3at
PoE

8 10/100M RJ45 PoE/PSE, support IEEE802.3af 15.4W / IEEE802.3at 30W

Working mode:auto detect powered device,stop powering if not PD device

Wavelength 850nm/1310nm/1490nm/1550nm/
Transmission distance

Fiber,multi-mode:2km; Single-mode:25/40/60/80/100/120Km

Single-fiber:25/40/60/80/100/120Km CAT5: 100M

Ports

8 10/100M RJ45 ports (POE/PSE): 10/100Mbs

1 100M FX uplink port: 100Mbps

MAC 2K
Buffer memory space 1Mbit
Bit error rate <1/1000000000
MTBF 100000 hours
Power DC48V dual input redundant backup
Power consumption Whole device:7W POE/PSE: maximum240W
Working temperature Common:-10~60℃; -T (wide temperature range):-40~75℃
Storage temperature -40~80℃
Humidity 5%~90% non-condensing
Installation Wall mounting type
Dimension 30mm (H)×2190mm(W)×119mm (D)





Order information

No Type NMS Ports Output Power
1 Foway2209PF-8AF NO 8 10/100M PoE+ 1 100M FX uplink IEEE802.3af 15.4W, total 125w
2 Foway2209PF NO 8 10/100M PoE+ 1 100M FX uplink IEEE802.3af/at 15.4W/30W, total 125w
3 Foway2209PF-120W NO 8 10/100M PoE+ 1 100M FX uplink IEEE802.3af/at 15.4W/30W, total 240w
4 Foway2209PFM-8AF YES 8 10/100M PoE+ 1 100M FX uplink IEEE802.3af 15.4W, total 125w
5 Foway2209PFM YES 8 10/100M PoE+ 1 100M FX uplink IEEE802.3af/at 15.4W/30W, total 125w
6 Foway2209PFM-120W YES 8 10/100M PoE+ 1 100M FX uplink IEEE802.3af/at 15.4W/30W, total 240w





8 100M Rj45 Ports 1 100M Uplink Port 9 Port Ethernet Switch 0

8 100M Rj45 Ports 1 100M Uplink Port 9 Port Ethernet Switch 1
