8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports

8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports
8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports 8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports 8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports 8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports

Large Image :  8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports

Product Details:
Place of Origin: China, Guang dong
Brand Name: Hioso
Certification: CE, RoHS, CCC
Model Number: Foway2310PFSP
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 38X24X18 CM
Delivery Time: 3-10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000pcs/month

8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports

Description
Product Name: 10 Ports Poe Switch Wavelength: 850nm/1310nm/1490nm/1550nm
Bit Error Rate: <1/1000000000 MTBF: 100000 Hours
Working Temperature: -10~60℃ Storage Temperature: -40~80℃
High Light:

2 1000M SFP Ports poe ethernet switch

,

8 10/100M poe ethernet switch

,

2 1000M SFP Ports poe 10 port switch

10 Ports PoE Switch 8 10 / 100M PoE Ports + 2 1000M SFP Ports



Overview



HiOSO Foway2310PFSP series 10 ports 100M/1000M Security Industrial PoE Ethernet Switches, supply 8 10/100M RJ45 PoE ports and 2 1000M SFP cascaded/ring network uplink ports ; support auto discovery IEEE802.3af/at standard powered devices,auto stop powering the non standard poe devices;support to supply power to IP cameras,VoIP phones,wireless access points and other network devices;support to choose web or SNMP management; support to transmit HD video flow; apply to Security system, electronic power system and traffic system requirements.



Character

  • Support 8 10/100M RJ45 PoE ports and 2 1000M SFP ports ring network/cascaded Uplink,SFP port supports hot swap
  • Each PoE port supports auto detect the powered device
  • Support IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards
  • Support to establish Gigabit fiber ring/cascaded network
  • Support each port full rate, full-duplex non-blocking forwarding
  • Support WEB management and SNMP (optional),support RSR (Rapid Super Ring) tech
  • 8K MAC learning, 1Mbit storage and forward cache space,7.6G back plane bandwidth
  • Each RJ45 port adopts anti-high voltage circuit, strengthen the lightning protection and anti-interference ability
  • Supply redundant dual power input ports, enhance reliability
  • Metal casing with Wall mounting design , better for heat dissipating and installation



Parameter Specification
Standard IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet,IEEE802.3z 1000Base-SX/LX Gigabit Ethernet,IEEE802.3x Flow control,IEEE802.1q VLAN,IEEE802.1p QoS, IEEE802.1d Spanning Tree,IEEE802.1w RSTP IEEE802.3af,IEEE802.3at
PoE

8 10/100M RJ45 PoE/PSE, support IEEE802.3af 15.4W / IEEE802.3at 30W

Working mode:auto detect powered device,stop powering if not PD device

Wavelength 850nm/1310nm/1490nm/1550nm/
Transmission distance 1000M Fiber,multi-mode:220m(fiber size 62.5/125μm)/550m(fiber size 50/125μm); Single-mode:10/20/40/60/80/100/120Km;Single-fiber:10/20/40/60/80/100/120Km CAT5: 100M
Ports

8 10/100M RJ45 ports (POE/PSE);

2 1000M SFP ports: 1 Gbps, 1000M SFP / 1000M Copper SFP

MAC 8K
Buffer memory space 1Mbit
Bit error rate <1/1000000000
MTBF 100000 hours
Power

DC48V dual input redundant backup (external power)

AC110V/220V@50HZ/60HZ&DC48V dual input redundant backup (inside power)

Power consumption Whole device:5.2W POE/PSE: maximum240W
Working temperature Common:-10~60℃; -T (wide temperature range):-40~75℃
Storage temperature -40~80℃
Humidity 5%~90% non-condensing
Installation Wall mounting type (external power), desk type/1U rack (inside power)
Dimension

30mm (H)×219mm(W)×119mm (D) (external power)

44mm (H)×276mm(W)×190mm (D) (inside power)





8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports 0

8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports 1
