Black 8 100M SFP Fiber Ports 1550nm Fiber Optic Switch AC220V

Black 8 100M SFP Fiber Ports 1550nm Fiber Optic Switch AC220V
Black 8 100M SFP Fiber Ports 1550nm Fiber Optic Switch AC220V Black 8 100M SFP Fiber Ports 1550nm Fiber Optic Switch AC220V Black 8 100M SFP Fiber Ports 1550nm Fiber Optic Switch AC220V Black 8 100M SFP Fiber Ports 1550nm Fiber Optic Switch AC220V Black 8 100M SFP Fiber Ports 1550nm Fiber Optic Switch AC220V

Large Image :  Black 8 100M SFP Fiber Ports 1550nm Fiber Optic Switch AC220V

Product Details:
Place of Origin: China, Guang dong
Brand Name: Hioso
Certification: CE, RoHS, CCC
Model Number: FOWAY1309FC
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: 50X35X15 cm
Delivery Time: 2-10 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000psc/month
Contact Now

Black 8 100M SFP Fiber Ports 1550nm Fiber Optic Switch AC220V

Description
Type: FTTx Solutions Model Number: FOWAY1309FC
Port: 8 100M SFP Ports+1 1000M Combo Uplink MAC: 8K
Working Temperature: -10~60℃ Power Consumption: 7.9W
Wavelength: 850nm/1310nm/1490nm/1550nm Dimension: 28mm (H)*193mm(W)*119mm (D)
High Light:

AC220V Fiber Optic Switch

,

1550nm Fiber Optic Switch

,

1550nm network switch with fiber optic port

FOWAY1309FC 8 ports 100M optical switch with high quality
Black 8 100M SFP Fiber Ports 1550nm Fiber Optic Switch AC220V 0

Feature
✔Support SFP hot swap
✔Support DHCP, PPPoE, ACL, LLDP
✔Support 8K MAC learning, 1Mbit storage and forward cache space, 4.6G back plane bandwidth,1632 byte large frame forwarding ✔Supports to substitute central fiber converter, simplify network structure, lower network establishing cost, reduce device fault ✔All optic ports, strengthen the an-interference ability
✔Metal casing design (support to hang on the wall), better for heat dissipation
Technical Specification
Parameter
Specification


Standard
IEEE802.3 10Base-T Ethernet,IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T , IEEE802.3z 1000Base-SX/LX Gigabit
Ethernet, IEEE802.1d Spanning Tree,IEEE802.1w Rapid STP,IEEE802.1s Multiple STP,IEEE802.1q Vlan,IEEE802.1q Qos,IEEE802.3ad
Trunk,IEEE802.3X Flow Control
Wavelength
850nm/1310nm/1490nm/1550nm



Distance
100M SFP multi-mode: 2Km
Single-mode: 25/40/60/80/100/120Km
Single-fiber single-mode: 25/40/60/80/100/120Km
1000M SFP multi-mode:220m (fiber 62.5/125μm) / 550m (fiber 50/125μm)
Single-mode:10/20/40/60/80/100/120Km
Single-fiber single-mode: 10/20/40/60/80/100/120Km
Cat5:100m

Port
8 100M SFP fiber ports: 100Mbps
1 Gigabit Combo port:1 Gbps, 100M/1000M SFP&10/100/1000M RJ45
MAC
8K
Buffer memory space
1Mbit
Bit error rate
<1/1000000000
MTBF
100000 hours
Power
DC12V/AC220V
Power consumption
7.9W
Working temperature
-10~60℃
Storage temperature
-40~80℃
Humidity
5%~90% non-condensing
Dimension
28mm (H)×193mm(W)×119mm (D)
Details Images
Black 8 100M SFP Fiber Ports 1550nm Fiber Optic Switch AC220V 1
Product Usage
Black 8 100M SFP Fiber Ports 1550nm Fiber Optic Switch AC220V 2
