AC110V 10G SFP+ Uplink Port Fiber Optic Network Switch 28 port

AC110V 10G SFP+ Uplink Port Fiber Optic Network Switch 28 port
AC110V 10G SFP+ Uplink Port Fiber Optic Network Switch 28 port AC110V 10G SFP+ Uplink Port Fiber Optic Network Switch 28 port AC110V 10G SFP+ Uplink Port Fiber Optic Network Switch 28 port AC110V 10G SFP+ Uplink Port Fiber Optic Network Switch 28 port

Large Image :  AC110V 10G SFP+ Uplink Port Fiber Optic Network Switch 28 port

Product Details:
Place of Origin: China, Guang dong
Brand Name: Hioso
Certification: CE, RoHS, CCC
Model Number: FOWAY6200-28FS
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 54X32X18 cm
Delivery Time: 3-10 work days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 2000pcs/month

AC110V 10G SFP+ Uplink Port Fiber Optic Network Switch 28 port

Description
Name: 24 PORTS Switch Buffer Memory Space: 12Mbit
Bit Error Rate: <1/1000000000 Power: AC 110-230V
Standard: IEEE802.3 10Base-T Ethernet Wavelength: 850nm -- 1550nm
High Light:

SFP+ Uplink Port fiber optic network switch

,

AC110V fiber optic network switch

,

SFP+ Uplink Port optical bypass switch



28 Ports Fiber Optic Switch 24 1000M SFP Ports + 4 10G SFP + Uplink Port



Character

Support the default 100M,1000M SFP,the SFP-1000BaseT RJ45 and 10G SFP+ hot plug

Support full rate, full-duplex non-blocking forwarding at each port

Support DHCP,PPPoE,ACL,LLDP

All optic ports, strengthen the an-interference ability

Support the AC dual redundant power supply hot backup and DC12V/5A spare battery power

Standard 1U rack ,internal double cooling fan,better for heat dissipation,work stable .



Technical Specification
Parameter
Specification



Distance
100M SFP Multi-mode: 2km (fiber size 62.5/125μm or 50/125μm)
Single-mode: 20/40/60/80/100/120Km
Single-fiber single-mode: 25/40/60/80/100/120Km
1000M SFP Multi-mode: 220m (fiber size 62.5/125μm)/550m(fiber size 50/125
μm)
Single-mode: 10/20/40/60/80/100/120Km
Single-fiber single-mode:10/20/40/60/80/100/120Km
CAT5: 100m

Port
24 Gigabit SFP fiber ports: 1000Mbps,1000M SFP / SFP-1000BaseT
4 10G SFP+ port:10 Gbps, 1G SFP/10G SFP+
1 console management port
1 100M RJ45 management port
MAC
16K
Buffer memory space
12Mbit
Power consumption
33W
Working
temperature
-10~60℃
Storage temperature
-40~80℃
Humidity
5%~90% non-condensing
Dimension
44mm (H)×440mm(W)×210mm (D)





AC110V 10G SFP+ Uplink Port Fiber Optic Network Switch 28 port 0

AC110V 10G SFP+ Uplink Port Fiber Optic Network Switch 28 port 1



FAQ

Q : What is your main products?
A : EPON System, GPON System, Fiber Optic Switch, Converter and so on.

Q : Is it safe on payment for me as we are the first cooperation?
A : We can do trade assurance on Alibaba, which will guarantee your products receiving, we also accept other safe payment way as you want.

Q : Do you test all your goods before delivery?
A : Yes, we have professional engineers to test all devices before shipping.

Q : Can I have my own customized product?
A : Yes. We have our own R&D team and production line.

Q : Can I have a sample order?
A : Yes. We welcome sample order to test and check quality.
