Super Thin 16 1000M SFP 8 Combo Uplink Optical Bypass Switch 24 Port

Super Thin 16 1000M SFP 8 Combo Uplink Optical Bypass Switch 24 Port
Super Thin 16 1000M SFP 8 Combo Uplink Optical Bypass Switch 24 Port Super Thin 16 1000M SFP 8 Combo Uplink Optical Bypass Switch 24 Port Super Thin 16 1000M SFP 8 Combo Uplink Optical Bypass Switch 24 Port Super Thin 16 1000M SFP 8 Combo Uplink Optical Bypass Switch 24 Port

Large Image :  Super Thin 16 1000M SFP 8 Combo Uplink Optical Bypass Switch 24 Port

Product Details:
Place of Origin: China, Guang dong
Brand Name: Hioso
Certification: CE, RoHS, CCC
Model Number: FOWAY5200-24FS-8CM
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 54X32X18 cm
Delivery Time: 2-12 work days
Payment Terms: T/T, Western Union
Supply Ability: 2000pcs/month

Super Thin 16 1000M SFP 8 Combo Uplink Optical Bypass Switch 24 Port

Description
Item Name: Fiber Switch Ports: 16 Ports
Transmisson Rate: 100Mbps Power Supply: AC100-240v
Operating Temperature: -10-60℃ Storage Temperature: -40-80℃
High Light:

16 1000M SFP optical bypass switch

,

8 Combo Uplink optical bypass switch

,

16 1000M SFP fiber core switch

Fiber Optic Equipment 24 Porta Switch 16 1000M SFP + 8 Combo Uplink



Overview



HiOSO FOWAY5200-24FS-8C is a 24port 1000M fiber switch, with 16 1000M SFP fiber ports(1000M SFP or the SFP-1000BaseT RJ45 port Optional)and 8 1000M Combo port (100M / 1000M SFP port or 10/100/1000M RJ45 port optional) uplink.



FOWAY5200-24FS-8C supports SFP modules hot plug, and supports to work with other fiber switches, fiber converters and other devices with fiber ports.It supports WEB management and SNMP management Support super network high definition video frequency transmission ability ,Streamlined network structure, support dual power supply hot backup, applies to security system, electric system, traffic system requirements.



Character

  • Support 16 100/1000M SFP (or SFP-1000BaseT RJ45 ) access and 8 Gigabit Combo port (100M/1000M SFP optional, or 10/100/1000M RJ45 port)
  • Support the default 100M,1000M SFP and the SFP-1000BaseT RJ45 hot plug
  • Support full rate, full-duplex non-blocking forwarding at each port
  • Support DHCP,PPPoE,ACL,LLDP
  • Support 16K MAC learning, 6Mbit storage and forward cache space,128G back plane bandwidth,10KByte Large frame forwarding
  • All optic ports, strengthen the an-interference ability
  • Support the AC dual redundant power supply hot backup and DC12V/5A spare battery power
  • Standard 1U rack ,internal double cooling fan,better for heat dissipation,work stable .



Technical Specification

Parameter Specification
Standard IEEE802.3 10Base-T Ethernet,IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX Gigabit Ethernet, IEEE802.1d Spanning Tree Protocol,IEE802.1w Rapid STP,IEE802.1s Multiples STP,IEE802.1q Vlan,IEE802.1q Qos,IEE802.3ad Trunk,IEE802.3X Flow Control
Wavelength SFP:850nm/1310nm/1490nm/1550nm
Distance

100M SFP Multi-mode: 2km (fiber size 62.5/125μm or 50/125μm)

Single-mode: 20/40/60/80/100/120Km

Single-fiber single-mode: 25/40/60/80/100/120Km

1000M SFP Multi-mode: 220m (fiber size 62.5/125μm)/550m(fiber size 50/125 μm)

Single-mode: 10/20/40/60/80/100/120Km

Single-fiber single-mode:10/20/40/60/80/100/120Km
CAT5: 100m

Port

16 Gigabit SFP fiber ports: 1000Mbps,1000M SFP / SFP-1000BaseT

8 Gigabit Combo port:: 1 Gbps, 100M/1000M SFP&10/100/1000M RJ45

1 USB console port

MAC 16K
Buffer memory space 6Mbit
Bit error rate <1/1000000000
MTBF 100000 hours
Power AC 110-240V
Power consumption 30W
Working temperature -10~60℃
Storage temperature -40~80℃
Humidity 5%~90% non-condensing
Dimension 44mm (H)×440mm(W)×210mm (D)



Order information

No Type Managed Ports Power
1 FOWAY5200-24FS-8C Not 16 1000M SFP ports+8 Gigabit Combo uplink Built-in single power supply
2 FOWAY5200-24FS-8C-BP Not 16 1000M SFP ports+8 Gigabit Combo uplink Built-in dual power supply
3 FOWAY5200-24FS-8CM Support 16 1000M SFP ports+8 Gigabit Combo uplink Built-in single power supply
4 FOWAY5200-24FS-8CM-BP Support 16 1000M SFP ports+8 Gigabit Combo uplink Built-in dual power supply







Super Thin 16 1000M SFP 8 Combo Uplink Optical Bypass Switch 24 Port 0

Super Thin 16 1000M SFP 8 Combo Uplink Optical Bypass Switch 24 Port 1
