Product Details:
|
Name: | 5 Ports Din Rali Switch | Transmission: | 10/100/1000M |
---|---|---|---|
Ports: | 5 GE + 1FX PORTS | Buffer Space: | 1Mbit |
Power: | AC Or DC | Mac: | 4k Learning |
High Light: | 5 Rj45 Ports Din Rail Ethernet Switch,1000M Fx Port Din Rail Ethernet Switch,5 Rj45 Ports din mount poe switch |
5 Ports Din Rail Ethernet Switch 5 Rj45 Ports + 1 1000M Fx Port
Overview
Foway 4505TF series is a 4 ports Ethernet switch , which can implement mutual conversion between10Base-T/100Base-TX/1000Base-T twisted pair electrical signal and 1000Base-SX/LX optical signal. Foway 4505TF series media converter provide 2 RPS (Redundant power supply) input : 9.6 ~ 60 VDC and 18 ~ 30VAC , it can be connected to a DC or AC power supply. Besides, Foway 4505TF series can work under the -40 ~ 75°C , With IP30 environmental protection grade, suitable for any industry . Foway 4505TF series with the DIP switch , can enable or disable broadcast storm protection, for different industrial applications provide another flexible solution.
Feature
Technical Specification
Parameters | Specifications |
Access mode | 10/100/1000Mbps |
Wavelength | 850nm/1310nm/1550nm |
Transmission distance | Dual-fiber multi-mode: 2Km; dual-fiber single-mode: 25/40/60/80/100/120Km;single-fiber single-mode: 25/40/60/80/100Km Category-5 twisted pairs: 100m |
Port | Four RJ45 port: Connected to STP/UTP category-5 twisted pairs One fiber port: Multi-mode – SC or ST (fiber size: 50,62.5/125μm) Single mode – SC/FC fiber port (fiber size: 9/125μm) Single-fiber single-mode – SC/FC fiber port (fiber size: 9/125 μ m) |
Conversion mode | Medium conversion, storing and forwarding/straight-through |
MAC address table | 4 K |
Buffer space | 2Mbit |
Flow control | Full duplex state: flow control; half-duplex state: back pressure mode |
Delay | 9.6us |
Bit error rate | <1/1000000000 |
MTBF | 100,000 hours |
LED | FX LINK/ACT (fiber link/action) SPD (twisted pair: transmission rate of 1000M) TP LINK/ACT (twisted pair link/action);P1 (power supply P1) ,P2(power supply P2) |
Power | 12/24/48 VDC,18 ~ 30VAC input |
Power consumption | 4W |
Operating temperature | -40~75°C |
Operating humidity | 5%~90% |
Storage temperature | -40~85°C |
Storage humidity | 5%~95% (non-condensing) |
Dimensions | 115mm×30mm×70mm (height * width * depth) |
