8K MAC 24 100M Tp 2 1000M Combo 26 Port Gigabit Switch 11W AC100V

8K MAC 24 100M Tp 2 1000M Combo 26 Port Gigabit Switch 11W AC100V
8K MAC 24 100M Tp 2 1000M Combo 26 Port Gigabit Switch 11W AC100V 8K MAC 24 100M Tp 2 1000M Combo 26 Port Gigabit Switch 11W AC100V 8K MAC 24 100M Tp 2 1000M Combo 26 Port Gigabit Switch 11W AC100V 8K MAC 24 100M Tp 2 1000M Combo 26 Port Gigabit Switch 11W AC100V

Large Image :  8K MAC 24 100M Tp 2 1000M Combo 26 Port Gigabit Switch 11W AC100V

Product Details:
Place of Origin: China, Guang dong
Brand Name: Hioso
Certification: CE, RoHS, CCC
Model Number: FOWAY2326TFCP
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 54X32X18 cm
Delivery Time: 3-10 working days
Payment Terms: T/T, Western Union
Supply Ability: 4000pcs/month

8K MAC 24 100M Tp 2 1000M Combo 26 Port Gigabit Switch 11W AC100V

Description
Product Name: 26 Port Switch MAC Learning: 8K MAC
Standard: IEEE802.1d Distance: CAT5: 100M
Power: AC100~240V Consumption: 11W
High Light:

24 100M Tp 26 port gigabit switch

,

2 1000M Combo 26 port gigabit switch

,

2 1000M Combo switch with fiber optic ports

26 Port Ethernet Access Switch 24 100M Tp + 2 1000M Combo Ports



Overview

HiOSO Foway2326TFCP series 26 ports 100M/1000M Security Industrial Ethernet switch, supply 24 10/100M RJ45 ports, 2 1000M Combo ports(100M/1000M SFP or 10/100/1000M RJ45);support SFP hot swap. It supports to work with fiber switches, fiber media converters, and other terminal devices with fiber port. It supports HD video flow transmission; support to establish redundant back bone ring type network; apply to security system, electric power system, and traffic system requirements.



Character

  • Support each port full rate, full-duplex non-blocking forwarding
  • Support WEB management and SNMP (optional)
  • 8K MAC learning, 3Mbit storage and forward cache space,22.8G back plane bandwidth
  • Supply redundant dual power input ports, enhance reliability
  • Standard 1U rack design,dust-proof,no noise,convenient for installation

Technical Specification

Parameter Specification
Wavelength SFP: 850nm/1310nm/1490nm/1550nm
Transmission distance

100M fiber:multi-mode: 2km ;Single-mode:25/40/60/80/100/120Km;

Single-fiber single-mode:25/40/60/80/100/120Km; 1000M fiber:multi-mode: 220m (fiber size 62.5/125μm)/550m (fiber size 50/125μm)

Single-mode:10/20/40/60/80/100/120Km;

Single-fiber single-mode:10/20/40/60/80/100/120Km; CAT5: 100M

Ports 24 10/100M RJ45 ports; 2 1000M Combo ports
MAC 8K
Buffer memory space 3Mbit
Installation Standard 1U rack
Dimension 44mm (H)×440mm(W)×210mm (D)


Order information

No Type NMS Port Power
1 Foway2326TFCP NO 24 10/100M RJ45 +2 1000M Combo ports AC220V





8K MAC 24 100M Tp 2 1000M Combo 26 Port Gigabit Switch 11W AC100V 0

8K MAC 24 100M Tp 2 1000M Combo 26 Port Gigabit Switch 11W AC100V 1
