Product Details:
|
| Product Namee: | Wifi ONU | Ports: | 1GE 3FE+WIFI |
|---|---|---|---|
| Rate: | 10/100/1000Mbps | Type: | FTTx Solutions |
| Supports Dual Mode: | Can Access GPON/EPON OLT | Power Supply: | DC12V/1A |
| Power Consumption: | <6W | Net Weight: | <0.4KG |
| Highlight: | FTTH Solution XPON ONU,1G3F XPON ONU,Easy Manage XPON ONU |
||
XPON 1G3F+WIFI
10/100/1000Mbps auto adaptive Ethernet(RJ45),1 GPON interface, Plastic Casing, External power supply adapter
| Technical Item | Details |
| PON interface |
1 E/GPON port(EPON PX20+ and GPON Class B+) Upstream: 1310nm; Downstream: 1490nm SC/UPC connector Receiving sensitivity: ≤-28dBm Transmitting optical power: 0.5~+4dBm Transmission distance: 20KM |
| LAN interface | 1x10/100/1000Mbps and 3x10/100Mbps auto adaptive Ethernet interfaces. Full/Half, RJ45 connector |
| WIFI Interface |
Compliant with IEEE802.11b/g/n Operating frequency: 2.400-2.4835GHz support MIMO, rate up to 300Mbps 2T2R,2 external antenna 5dBi Support: Multiple SSID Channel:13 Modulation type: DSSS,CCK and OFDM Encoding scheme: BPSK,QPSK,16QAM and 64QAM |
| LED | 9 LED, For Status of POWER, LOS, PON, LAN1~LAN4, WIFI, WPS |
| Push-Button | 3, for Function of Power on/off, Reset, WPS |
| Operating condition |
Temperature : 0℃～+50℃ Humidity :10%～90%(non-condensing) |
| Storing Condition |
Temperature : -40℃～+60℃ Humidity :10%～90%(non-condensing) |
| Power supply | DC 12V/1A |
| Power Consumption | <6W |
| Net Weight | <0.4kg |
Application
Feature
Datasheet Download:1G3F WIFI.pdf
