Product Details:
Place of Origin: China, Guang dong
Brand Name: Hioso
Certification: CE, RoHS, CCC
Model Number: HA7308C-BP
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: 40X35X15 cm
Delivery Time: 2-10 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: negotiable

HiOSO FTTH EPON OLT 8 PON OLT 4SFP GE 4 Combo Dual Power Supply Support Other Brand ONU ONT

Description
Product Name: Epon Olt Type: FTTH
Pon Ports: 8 SFP Pon Ports Max Splitting Ratio: 1:64
Uplink: 4 SFP Ports + 4 Combo(SFP/TP) Ports Warranty: 3 Years
High Light:

FTTH Type Hioso EPON OLT

,

8 PON Hioso EPON OLT

,

Dual Power Supply 8 PON OLT


HA7308C Rack Type 8-PON OLT Dual power supply

FOWAY1510PFS 8 PORT POE SWITCH.pdf





HA7308C is a U rack type 8 SFP PON ports OLT.HA7308C works with HA7200 series ONU and ODN, to establish a passive optic network. The whole system supports 8-PON, 512 ONUs. It supports SNMP management and meets China Telecom EPON standards.


Feature

✔Supply 8 SFP PON ports, 4 1000M SFP ports, 4 Combo uplink ports

✔Each PON port support 1.64 split ratio, total 512 ONUs access

✔Distance can reach 20km under 1:32 split ratio

✔Support to work with HA400/HA7200 series ONUs to establish passive network

✔Support WEB and SNMP, integrate switching function

✔1U rack design, inside fan,better for heat dissipating and reliability operating

✔Apply for town,village fiber network and surveillance, apply for FTTX network,
to transmit IP phone, data,IPTV and other IP services access



Technical Specification

Parameter Specification
Operating wavelength 1310(RX) /1490(TX)
Optical power +2.5 ~ +7dBm
Receiving sensitivity -27dBm
Max distance 20km
Max splitter ratio 1:64
Capacity 8 SFP PON, each PON supports max 64pcs ONU, total 512pcs ONU
MAC 16k
Uplink port 4 SFP ports + 4 Combo(SFP/TP) ports
PON port 8 SFP 1000M fiber ports
Control port

1 10/100/1000M RJ45 port

1 Console(RJ45), to debug the device

1 USB port

MTBF 100,000 hours
EPON traits Support AES-128 encryption to each Logical Link Identifier
Support powerful OAM function, implement telnet management, maintenance and upgrade
Support auto discovery and auto register of ONU (real-time operation)
Network management Support GUI management based on SNMP
Support WEB management and Telnet GUI management based on CLI



Working Environment

Parameter Specification
Power Dual AC100~240V 50/60HZ
Power Consumption 35W
Operating temperature -10—55 C
Storage temperature -40—70 C
Humidity 5%--90% non-condensing
Dimension 440mm(length) * 260mm(width) * 44mm(height)


HiOSO FTTH  EPON OLT 8 PON OLT 4SFP GE 4 Combo Dual Power Supply Support Other Brand ONU ONT 0HiOSO FTTH  EPON OLT 8 PON OLT 4SFP GE 4 Combo Dual Power Supply Support Other Brand ONU ONT 1
