Heat Dissipating IEEE802.3af 15.4W 2 Fiber Ports POE Switch

Certification
China HiOSO Technology Co., Ltd. certification
China HiOSO Technology Co., Ltd. certification
I'm Online Chat Now

Heat Dissipating IEEE802.3af 15.4W 2 Fiber Ports POE Switch

Heat Dissipating IEEE802.3af 15.4W 2 Fiber Ports POE Switch
Heat Dissipating IEEE802.3af 15.4W 2 Fiber Ports POE Switch Heat Dissipating IEEE802.3af 15.4W 2 Fiber Ports POE Switch Heat Dissipating IEEE802.3af 15.4W 2 Fiber Ports POE Switch Heat Dissipating IEEE802.3af 15.4W 2 Fiber Ports POE Switch

Large Image :  Heat Dissipating IEEE802.3af 15.4W 2 Fiber Ports POE Switch

Product Details:
Place of Origin: China
Brand Name: HiOSO
Certification: CCC
Model Number: FOWAY1209PF
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 38X24X18 CM
Delivery Time: 3-10 work days
Payment Terms: L/C, D/A
Supply Ability: 2000pcs/month

Heat Dissipating IEEE802.3af 15.4W 2 Fiber Ports POE Switch

Description
Item: Poe Switch Poe: 8 Poe Ports
Port: 2 Fiber Ports Support: IP Camera
MAC: 2K Storage: 1M
High Light:

IEEE802.3af 15.4W POE Switch

,

2 Fiber ports POE Switch

,

2 Fiber ports poe network

9 Port Ethernet Poe Switch 8 100M PoE Ports + 1 100M FX Port



Character

  • Support maximum 8 100M RJ45 PoE ports and 1 100M fiber uplink port
  • Each PoE port supports to auto discovery the standard power receiving devices
  • Support IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards
  • Support each 100M port full rate, full-duplex non-blocking forwarding
  • Support 2K MAC learning, 1Mbit storage and forward cache space, 2G back plane bandwidth
  • Each RJ45 port using anti-high voltage circuit, strengthen the lightning protection and anti-interference ability
  • Support to provide wall-mounted hanger better for installation if need, external power design and metal casing better for heat dissipating



Technical Specification

Parameter Specification
Standard IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3af, IEEE802.3at, IEEE802.1d Spanning Tree
PoE

PoE ports: 8

Standard and power consumption:IEEE802.3af 15.4W, IEEE802.3at 30W

Working mode: auto discovery power receiving devices and auto power supply/power cutting

Wavelength 850nm/1310nm/1490nm/1550nm
Distance

multi-mode: 2Km

Single-mode: 20/40/60/80/100/120Km

Single-fiber single-mode: 20/40/60/80/100/120Km

Port

8 100M PoE ports: 10/100Mbps

1100M FX uplink port: fiber port SC-100Mbps

MAC 2K
Buffer memory space 1Mbit
Bit error rate <1/1000000000
MTBF 100000 hours
Power DC48V
Power consumption 7W, PoE power supplying maximum 240W
Working temperature -10~60℃
Storage temperature -40~80℃
Humidity 5%~90% non-condensing
Dimension 28mm (H)×193mm(W)×119mm (D)





Order information

No Product code NMS Ports PoE ports
1 FOWAY1209PF No 8 100M RJ45+1 100M fiber uplink 8 PoE ports IEEE802.3af/at 125W
2 FOWAY1209PF-240W No 8 100M RJ45+1 100M fiber uplink 8 PoE ports IEEE802.3af/at 240W
3 FOWAY1209PFM Yes 8 100M RJ45+1 100M fiber uplink 8 PoE ports IEEE802.3af/at 125W
4 FOWAY1209PFM-240W Yes 8 100M RJ45+1 100M fiber uplink 8 PoE ports IEEE802.3af/at 240W





Heat Dissipating IEEE802.3af 15.4W 2 Fiber Ports POE Switch 0

Heat Dissipating IEEE802.3af 15.4W 2 Fiber Ports POE Switch 1
