HiOSO WEB Management Auto Discovery FTTH GPON Modem 1 Port

Certification
China HiOSO Technology Co., Ltd. certification
China HiOSO Technology Co., Ltd. certification
I'm Online Chat Now

HiOSO WEB Management Auto Discovery FTTH GPON Modem 1 Port

HiOSO WEB Management Auto Discovery FTTH GPON Modem 1 Port
HiOSO WEB Management Auto Discovery FTTH GPON Modem 1 Port HiOSO WEB Management Auto Discovery FTTH GPON Modem 1 Port HiOSO WEB Management Auto Discovery FTTH GPON Modem 1 Port HiOSO WEB Management Auto Discovery FTTH GPON Modem 1 Port

Large Image :  HiOSO WEB Management Auto Discovery FTTH GPON Modem 1 Port

Product Details:
Place of Origin: China
Brand Name: HiOSO
Certification: CCC
Model Number: HA411G
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 20*15*10cm
Delivery Time: 3-7 working days
Payment Terms: L/C, T/T
Supply Ability: 5000pcs / month

HiOSO WEB Management Auto Discovery FTTH GPON Modem 1 Port

Description
Name: 1 Port Xpon Onu Application: Fiber To The Home
Wavelength: Tx 1310nm/Rx1490nm Management: WEB Management, With IP
Color: White Chipset: ZTE
High Light:

HiOSO ftth gpon modem

,

1 Port ftth gpon modem

,

1 Port gpon fiber modem

1 Port Gpon Onu Auto Discovery Epon / Gpon Olt Work For Ftth Solutions



Overview

HA411G GPON/XPON ONT is designed for fulfilling FTTH ultra-broadband access request of home and SOHO users. It is based on the stable and mature GPON technology, which has high performance/price ratio, and the technology of layer 2 as well.It supports both GPON and EPON OLT, auto discovery and register. It is highly reliable and easy to maintain, with guaranteed QoS, and fully compliant to ITU-T G.984 GPON standards.



Feature

  • Support ITU-T G984 Standard
  • Auto discovery EPON/GPON OLT
  • Supports 32 TCONT,256 gemports
  • Support ONU auto-discovery/Link detection/remote upgrade of software
  • Integrated remote configuration and maintenance function.
  • Functions like transceiver diagnostic monitoring, transmitter disable, etc
  • Fully compatibility with GPON OLT with different chipsets.
  • Support port monitoring, port mirroring, port rate limiting etc.
  • Support auto polarity detection of Ethernet ports (AUTO MDIX)
  • Support VLAN division and user separation to avoid broadcast storm
  • Support broadcasting storm resistance function



Technical items Description
Main chip ZTE
Uplink PON interface

1 GPON interface, SC single-mode/single-fibre,

uplink 1 .25Gbps, downlink 2.5Gbps

Downlink LAN interface

1* 10/100/1000Mbps

Full Duplex/Half Duplex, RJ45 connector

Wavelength Tx 1310nm, Rx 1490nm
Optical power 0~+4dBm
Receiving sensitivity -27dBm
Max transmission distance 20 km
Cache space 1.25MB
MTBF 100,000 hours



GPON trait

ITU-T G984 Standard

Supports 32 TCONT,256 gemports

Support the 984 standard AES128 encryption function

Support SBA and DBA

Network management WEB management, with IP
