Product Details:
Place of Origin: China
Brand Name: HiOSO
Certification: ccc
Model Number: HA7400G
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negoitable
Packaging Details: 30CM*25CM*10CM
Delivery Time: 2-7 work days
Payment Terms: T/T, Western Union
Supply Ability: 5000pcs / month

HiOSO Link Detection Auto Discovery Port 1ge GPON ONU For For Town

Description
Product Name: 1 Port Gpon Onu Wavelength: Tx 1310nm, Rx 1490nm
Application: FTTX Color: Black
Warranty: 3 Years Power Supply: DC12V
High Light:

HiOSO 1ge gpon onu

,

1ge gpon onu

,

HiOSO gpon modem

1 Gigabit Port Gpon Onu Support ITU-T G984 Standard Auto Discovery Gpon Olt



Feature

  • Support ITU-T G984 Standard
  • Auto discovery EPON/GPON OLT
  • Supports 32 TCONT,256 gemports
  • Support ONU auto-discovery/Link detection/remote upgrade of software
  • Integrated remote configuration and maintenance function
  • Functions like transceiver diagnostic monitoring, transmitter disable, etc
  • Fully compatibility with GPON OLT with different chipsets.
  • Support port monitoring, port mirroring, port rate limiting etc.
  • Support auto polarity detection of Ethernet ports (AUTO MDIX)
  • Support VLAN division and user separation to avoid broadcast storm



Technical items Description
Main chip ZTE / Realtek
Uplink PON interface

1 GPON interface, SC single-mode/single-fibre,

uplink 1 .25Gbps, downlink 2.5Gbps

Downlink LAN interface

1* 10/100/1000Mbps

Full Duplex/Half Duplex, RJ45 connector

Wavelength Tx 1310nm, Rx 1490nm
Optical power 0~+4dBm
Receiving sensitivity -27dBm
Max transmission distance 20 km
Cache space 1.25MB
MTBF 100,000 hours



GPON trait

ITU-T G984 Standard

Supports 32 TCONT,256 gemports

Support the 984 standard AES128 encryption function

Support SBA and DBA

Network management WEB management, with IP





HiOSO Link Detection Auto Discovery Port 1ge GPON ONU For For Town 0

HiOSO Link Detection Auto Discovery Port 1ge GPON ONU For For Town 1
