Product Details:
Place of Origin: China
Brand Name: HiOSO
Certification: CCC
Model Number: Foway2205TF
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 38X24X18 CM
Delivery Time: 3-10 working days
Payment Terms: T/T, Western Union
Supply Ability: 4000pcs/month

4 RJ45 Ports 1 100M FX Uplink Port Ethernet Access Switch 5 Port

Description
Item: 5 Ports Switch Support: 2K MAC Learning
Distance: CAT5: 100M Power: DC12V/1A
Humidity: 5%~90% Memory Space: 1Mbit
High Light:

4 RJ45 Ports Ethernet Access Switch

,

100M FX Uplink Port Ethernet Access Switch

,

4 RJ45 Ports fiber distribution switch

Ethernet Access Switch 4 RJ45 Ports + 1 100M FX Uplink Port 5 Port Switch



Overview



HiOSO Foway2205TF series 5 ports 100M Security Industrial Ethernet Switches, supply 4 10/100M RJ45 ports and 1 100M FX uplink port; support to choose web or SNMP management; support to transmit HD video flow; apply to Security system, electronic power system and traffic system requirements.



Character

  • Support 4 10/100M RJ45 ports and 1 100M FX uplink port
  • Support each port full rate, full-duplex non-blocking forwarding
  • Support WEB management and SNMP (optional)
  • Support 2K MAC learning, 1Mbit storage and forward cache space
  • Each RJ45 port adopts anti-high voltage circuit, strengthen the lightning protection and anti-interference ability
  • Supply redundant dual power input ports, enhance reliability
  • Metal casing with wall mounting design, external power , better for heat dissipating and installation



Technical Specification

Parameter Specification
Standard IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet,IEEE802.3x Flow control,IEEE802.1q VLAN,IEEE802.1p QoS, IEEE802.1d Spanning Tree
Wavelength 850nm/1310nm/1490nm/1550nm
Transmission distance

100M fiber:multi-mode: 2km

Single-mode:25/40/60/80/100/120Km;

Single-fiber single-mode:25/40/60/80/100/120Km;CAT5: 100M

Ports

4 10/100M RJ45 ports: 10/100Mbs

1 100M FX uplink port: 100Mbps SC/FC/ST fiber port

MAC 2K
Buffer memory space 1Mbit
Bit error rate <1/1000000000
MTBF 100000 hours
Power DC12V/1A dual input redundant backup
Power consumption 3.5W
Working temperature Common:-10~60℃; -T (wide temperature range):-40~75℃
Storage temperature -40~80℃
Humidity 5%~90% non-condensing
Installation Wall mounting type
Dimension 26mm (H)×140mm(W)×106mm (D)





Order information

No Type NMS Ports
1 Foway2205TF NO 4 10/100M RJ45 ports + 1 100M FX uplink
2 Foway2205TFM YES 4 10/100M RJ45 ports + 1 100M FX uplink
