Product Details:
Place of Origin: China
Brand Name: HiOSO
Certification: CCC
Model Number: Foway2505TF
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 38X24X18 CM
Delivery Time: 2-11 work days
Payment Terms: T/T, D/P
Supply Ability: 3000pcs/month

4 1000M RJ45 1 1000M Uplink Port 5 Port Switch 1000 Mbps 1Mbit Storage

Description
Name: Ethernet Switch Mac: 8K MAC Learning
Transmission: CAT5: 100M Error Rate: <1/1000000000
Working Temperature: -10~60℃ Humidity: 5%~90%
High Light:

1000M Uplink Port 5 port switch 1000 mbps

,

4 1000M RJ45 5 port switch 1000 mbps

,

1000M Uplink Port rj45 port switch

5 Ports 1000M Ethernet Access Switch 4 1000M RJ45 + 1 1000M Uplink Port



Overview



HiOSO Foway2505TF series 5 ports 1000M Security Industrial Ethernet Switches, supply 4 10/100/1000M RJ45 ports and 1 1000M FX uplink port; support to choose web or SNMP management; support to transmit HD video flow; apply to Security system, electronic power system and traffic system requirements.



Character

  • Support 4 10/100/1000M RJ45 ports and 1 1000M FX uplink port
  • Support WEB management and SNMP (optional)
  • Support 1K/8K MAC learning, 1Mbit storage and forward cache space
  • Each RJ45 port adopts anti-high voltage circuit, strengthen the lightning protection and anti-interference ability
  • Supply redundant dual power input ports, enhance reliability
  • Metal casing with Wall mounting design, external power , better for heat dissipating and installation



Technical Specification

Parameter Specification
Transmission distance

1000M fiber:multi-mode: 220m ; Single-mode:10/20/40/60/80/100/120Km;

Single-fiber single-mode:10/20/40/60/80/100/120Km;

CAT5: 100M

Ports

4 1000M RJ45 ports: 10/100/1000Mbs

1 1000M FX uplink port: 1000Mbps SC/FC fiber port

MAC 1K (8K optional)
Buffer memory space 1Mbit
Bit error rate <1/1000000000
MTBF 100000 hours



Order information

No Type NMS Ports
1 Foway2505TF NO 4 10/100/1000M RJ45 ports + 1 1000M FX uplink
2 Foway2505TFM YES 4 10/100/1000M RJ45 ports + 1 1000M FX uplink







4 1000M RJ45 1 1000M Uplink Port 5 Port Switch 1000 Mbps 1Mbit Storage 0

4 1000M RJ45 1 1000M Uplink Port 5 Port Switch 1000 Mbps 1Mbit Storage 1





Company Introduction
HiOSO Technology Co., Ltd. was founded in 2002, being dedicated to the research, production and sale of optical communication network products based on FTTH and FTTD.Our main products include EPON systems, fiber optic media converters, CWDM system equipment, digital video optical transceivers, converter racks, single/multi-mode converters, PDH and fiber modems.
